Dimensions of Software Architecture: Balancing Concerns

·833 words·4 mins· loading · ·
Software Architecture Software Architecture Technical Debt Maintainability Scalability Performance

On This Page

Table of Contents
Share with :

Dimensions of Software Architecture
#

Call these “Architectural Concern Categories” or “Dimensions of Software Architecture” or “Axes of Architectural Design” it is your choice. Here I am referring them as Dimensions of Software Architecture. They are extremely important for any software solution creator or software product maker. In this article we are trying to understand these dimensions. I am aware there is some overlapping between these terms.

Execution Models
#

How your code runs: in sequence, in parallel, or in reaction to events.

  • Synchronous: Step-by-step, blocking (print(read_file()))
  • Asynchronous: Non-blocking (await fetch())
  • Concurrent: Tasks progress together (threading, asyncio)
  • Parallel: Truly simultaneous (multiprocessing)
  • Event-driven: React to events (onclick, Node.js)
  • Reactive : A model where the system reacts to inputs (data/events) as they come in.
  • Event-driven : System behavior is determined by events or messages.
  • Blocking / Non-blocking : Whether a thread waits (blocks) or not when performing an operation (like I/O).
  • Multi-threaded : Uses multiple threads of execution.
  • Single-threaded : Only one thread handles all operations (e.g., Node.js with event loop).
  • Actor model : Independent actors communicate via message passing (e.g., Erlang, Akka).
  • Coroutine-based : Lightweight cooperative threads (e.g., Python asyncio, Go routines).

Communication Patterns
#

How components talk to each other.

  • Request-Response: Client-server (HTTP REST)
  • Pub-Sub: Send and forget (Kafka, MQTT)
  • Message Queue: Tasks queued (RabbitMQ)
  • Streaming: Continuous flow (WebSocket, gRPC stream)
  • RESTful APIs : HTTP-based stateless communication.
  • gRPC : High-performance RPC using Protocol Buffers.
  • WebSockets : Bi-directional communication over a single TCP connection.
  • Polling / Long Polling : Repeated or extended HTTP requests to simulate real-time communication.
  • Shared Memory : Threads/processes access common memory space (risky but fast).
  • Remote Procedure Call (RPC) : Directly invoke methods across networks.
  • Signal / Slot : Observer-based pattern used in GUIs or reactive systems.

Architectural Styles
#

High-level design structure of a system.

  • Monolithic: All-in-one (Django app)
  • Layered: Separate tiers (MVC, 3-tier)
  • Microservices: Small independent services (Netflix)
  • Event-driven architecture: Events trigger behavior (e-commerce order placed)
  • Service-Oriented Architecture (SOA) : Services communicate over a network, often with an enterprise service bus (ESB).
  • Serverless : Logic is deployed as short-lived functions (e.g., AWS Lambda).
  • Client-Server : Traditional model with a requesting client and responding server.
  • Peer-to-Peer (P2P) : Every node is both a client and server.
  • Hexagonal (Ports & Adapters) : Decouples core logic from external systems via interfaces.
  • Clean Architecture : Emphasizes separation of concerns and independence of frameworks/UI.
  • Onion Architecture : Similar to Clean Architecture, with concentric layers.
  • Microkernel / Plugin : Core system extended via plugins (e.g., IDEs).
  • Pipeline / Filter : Data passes through a sequence of processing steps.
  • Blackboard Architecture : Components contribute to and draw from a shared data structure.
  • CQRS (Command Query Responsibility Segregation) : Separate read and write models.
  • Event Sourcing : Store changes as a sequence of events.
  • Saga Pattern : Handle long-running distributed transactions.
  • Circuit Breaker : Prevent failure propagation in microservices.
  • Strangler Fig Pattern : Gradually replace a legacy system.
  • Bulkhead Pattern : Isolate failures in one part of a system.
  • Sidecar Pattern : Attach helper services to main service (common in service mesh).

Deployment & Runtime Models
#

How and where the system runs.

  • Containers: Lightweight runtime (Docker)
  • Serverless: No server management (AWS Lambda)
  • Orchestrated/Cloud-native: Designed for cloud (Kubernetes)
  • Edge Computing : Computation close to the data source (IoT, CDN).

Scalability & Availability
#

How the system handles load and stays online.

  • Load balancing: Distribute requests (Nginx)
  • Replication: Data copies (MongoDB replica set)
  • Sharding: Split data (Cassandra)
  • Auto-scaling: Elastic capacity (AWS EC2 Auto Scaling)
  • Horizontal Scaling : Add more machines.
  • Vertical Scaling : Add more resources to existing machine.
  • High Availability : System remains available despite failures.

Data Handling & Consistency
#

How data is stored and kept accurate.

  • ACID: Reliable DB transactions (PostgreSQL)
  • BASE: Eventually consistent (Cassandra)
  • CQRS: Read/write separation
  • Event Sourcing: Store change events (Kafka log)

Resilience & Fault Tolerance
#

How the system recovers from failure.

  • Retry: Try again on failure
  • Circuit Breaker: Stop failing requests (Netflix Hystrix)
  • Fallback: Backup response logic
  • Failover : Automatic switching to backup systems.

Security Boundaries
#

How the system protects itself and data.

  • Authentication: Identity check (OAuth)
  • Authorization: Access control (JWT, RBAC)
  • TLS/SSL: Encryption in transit

Modularity & Extensibility
#

How easily the system can evolve.

  • Plugin system: Add-on features
  • Inversion of Control (IoC): Framework calls your code (Spring)
  • Dependency Injection: Inject components

Observability & Monitoring
#

How the system is monitored and debugged.

  • Logging: App logs (loguru, winston)
  • Metrics: Numbers to track (Prometheus)
  • Tracing: Flow tracking (OpenTelemetry)

Dev & Release Lifecycle
#

How the system is built, tested, and released.

  • CI/CD: Automated build/deploy (GitHub Actions)
  • Blue-Green Deployment: Zero downtime switch
  • Canary Release: Small rollout

Orthogonal Concepts
#

  • Scalability : Ability to grow with load.
  • Resilience : Ability to recover from failure.
  • Observability : System visibility through logging, tracing, and metrics.
  • Maintainability : Ease of making changes over time.
  • Security-by-Design : Security considered from the outset.
  • Idempotency : Repeated operations produce the same result.
  • Stateless vs Stateful : Whether or not a component retains memory of previous interactions.
